Tritan Angular Contact Ball Bearing,3100lb.,NBR 5304 2RS/C3 PRX

Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 3304/5304, Bore Diameter 20 mm, Cage Material Polyamide, Closure Double Sealed, Contact Bearing Type Angular Contact, Lubricant Material SRI 2 Grease, Polyrex EM Grease, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 11,000 RPM, Maximum Temperature 175 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows Two, Outside Diameter 52 mm, Overall Width 22.2 mm, Ring Material Alloy Steel

• ABEC Rating:1
• ABEC Tolerance:1
• Ball Material Grade:AISI 52100
• Ball Material:Alloy Steel
• Bearing Industry Number:3304/5304
• Bearing Type:Single Bearing
• Bore Diameter Tolerance:+/-0.1 mm
• Bore Diameter:20 mm
• Brand & Part Number for Bearing Industry Nu
• Cage Material & Brand:Thermoplastic : TRITAN
• Cage Material:Thermoplastic
• Contact Bearing Type:Angular Contact
• Country of Origin (subject to change):China
• Item:Angular Contact Ball Bearing
• Maximum Speed:11,000 RPM
• Maximum Temperature:175 Degrees C
• Minimum Temperature:-40 Degrees C
• Number of Rows:Two
• Outside Dia.:52mm
• Outside Diameter Tolerance:+/-0.013 mm
• Outside Diameter:52 mm
• Overall Width:22.2 mm
• Package Quantity:1
• Seal Material:Nitrile Rubber
• Seal Type:Contact
• Shield Material:Not Applicable
• Standards:ISO Certified 9001
• Static Load Capacity (Lb.):3,100 lb
• Static Load Capacity:3372 Lbf
• Static Radial Load Capacity:13,790 N
• System of Measurement:Metric
• Temp. Range (F):-40 Degrees to 350 Degrees
• Temp. Range:-20 to +248° F
• Type:Double Row
• Width:22.2mm
